    Note to the Instructor - Triangle Geometry

    Triangles, being the focus of Trigonometry, deserve their own full section. Focus here is on types of triangles, the Pythagorean Theorem, the special triangles, and the area of a triangle (not requiring trigonometric functions). Many exercises involving the \( 30^{ \circ } \)-\( 60^{ \circ } \)-\( 90^{ \circ } \) and \( 45^{ \circ } \)-\( 45^{ \circ } \)-\( 90^{ \circ } \) that would normally be presented in Right Triangle Trigonometry are found in this section and its homework (but without reference to the trigonometric functions). Similar triangles are held off until next section.

    Prerequisite Skills
    • Sets and Numbers
      • Inequalities and Inequality Notation
    • Geometry
      • Common Volumes
    • Simplifying Expressions
      • Properties of Radicals and Simplifying Expressions Involving Roots
    • Solving Equations
      • Solving Quadratic Equations (by Extraction of Roots)
      • Solving Radical Equations
    • Solving Inequalities
      • Solving Linear Inequalities
      • Solving Compound Inequalities

    Triangle Basics

    Definition: Triangle

    When three line segments bound a portion of the plane, the resulting shape is called a triangle (also known as a three-sided polygon). The line segments are called the sides of the triangle. A point where two sides meet is called a vertex of the triangle. Finally, the angle formed in the triangle's interior where two sides meet is called an angle of the triangle.

    Theorem: Triangle Sum

    The sum of the interior angles in a triangle is \( 180^{\circ} \).

    Proof
    Given the triangle, \( \triangle ABC \), draw a line parallel to side \( \overline{BC} \) going through vertex \( A \) (see the figure below).
    Since \( \angle q + \angle a + \angle p \) forms a straight angle,\[ \angle q + \angle a + \angle p = 180^{\circ}. \nonumber \]Moreover, the line segment \( \overline{AC} \) is a transversal for the parallel lines \( \overline{BC} \) and \( \overline{DE} \). Therefore, \( \angle c = \angle p \). By a similar argument, \( \angle b = \angle q \). Hence,\[ \angle b + \angle a + \angle c = 180^{\circ}. \nonumber \]Thus, the sum of the angles of a triangle is \( 180^{\circ} \).

    The Triangle Inequality

    Theorem: Triangle Inequality

    In any triangle, we must have that\[p + q > r, \nonumber \]where \(p, q\), and \(r\) are the lengths of the sides of the triangle (see the figure below).

    Screen Shot 2022-09-11 at 5.25.09 PM.png

    That is, the sum of the lengths of any two sides of a triangle is greater than the length of the other side.

    Types of Triangles

    Equilateral Triangles

    Definition: Equilateral Triangle

    A triangle in which all three sides have the same length is called an equilateral triangle.

    Theorem: Angles of an Equilateral Triangle

    All the angles of an equilateral triangle are equal.

    Isosceles Triangles

    Definition: Isosceles Triangle

    A triangle in which at least two sides are of equal length is called an isosceles triangle. The angle between the equal sides is called the vertex angle, and the other two angles are called the base angles.

    Theorem: Angles of an Isosceles Triangle

    The base angles of an isosceles triangle are equal.

    We introduce another common notation used throughout Geometry - the tick mark. We use tick marks on line segments to denote they have equal length. Similarly, tick marks on angles denote that the angles have the same measure.

    Scalene Triangles

    Definition: Scalene Triangle

    A triangle in which none of the sides have equal length (and, therefore, none of the angles are equal) is called a scalene triangle.

    Classification of Triangles by Largest Angle

    Obtuse Triangles

    Definition: Obtuse Triangle

    A triangle which contains an obtuse angle is called an obtuse triangle.

    1.2 Obtuse Triangle.png
    Theorem: Angles of an Obtuse Triangle

    In an obtuse triangle, one angle must be greater than \( 90^{ \circ } \), and the remaining two angles must each be less than \( 90^{ \circ } \).

    Right Triangles

    Definition: Right Triangle

    A triangle containing a right angle is called a right triangle.

    1.2 Right Triangle.png

    Right Triangles: The Pythagorean Theorem

    Theorem: Pythagorean Theorem

    In a right triangle, if \(c\) is the length of the hypotenuse, and the lengths of the two legs are denoted by \(a\) and \(b\) (as shown in the figure below), then\[a^2 + b^2 = c^2. \nonumber \]

    Screen Shot 2022-09-11 at 5.31.23 PM.png
    Caution

    The Pythagorean Theorem is valid only for right triangles!

    Acute Triangles

    Definition: Acute Triangle

    A triangle in which all angles are less than \( 90^{ \circ } \) is called an acute triangle.

    1.2 Acute Triangle.png

    Special Triangles

    Definition: Altitude of a Triangle

    The altitude of a triangle is a line segment drawn from a vertex of the triangle perpendicular to the opposite side (or the line containing the opposite side).

    Theorem: Altitudes and Right Angles

    The altitude of a triangle represents the shortest distance from the vertex to the opposite side and forms a \( 90^{ \circ } \) angle with that side.

    The \( 30^{ \circ } \)-\( 60^{ \circ } \)-\( 90^{ \circ } \) Triangle

    Definition: \( 30^{ \circ } \)-\( 60^{ \circ } \)-\( 90^{ \circ } \) Triangle

    A right triangle in which one angle is \( 30^{ \circ } \) and another angle is \( 60^{ \circ } \) is called a \( 30^{ \circ } \)-\( 60^{ \circ } \)-\( 90^{ \circ } \) triangle.

    Theorem: Side Relationships for a \( 30^{ \circ } \)-\( 60^{ \circ } \)-\( 90^{ \circ } \) Triangle

    In any right triangle in which the two acute angles are \( 30^{ \circ } \) and \( 60^{ \circ } \), the hypotenuse is always twice the length of the shortest side (the side opposite the \( 30^{ \circ } \) angle), and the remaining side (opposite the \( 60^{ \circ } \) angle) is always \( \sqrt{3} \) times the shortest side.

    1.2 30-60-90 Theorem.jpg
    Proof

    Consider an equilateral triangle with side lengths \( 2a \), as shown in the figure below.

    1.2 30-60-90 new.png

    Since this triangle is equilateral, each angle is \( 60^{ \circ } \). Drawing an altitude divides the triangle into two smaller triangles. Since the altitude is perpendicular to the base, each of these smaller triangles is a right triangle. Moreover, since one angle in each of these smaller right triangles is \( 60^{ \circ } \), the remaining angle must be \( 30^{ \circ } \). Furthermore, the side opposite the \( 30^{ \circ } \) angle must have length \( a \) (in the original equilateral triangle, the side opposite \( 60^{ \circ } \) had length \( 2a \), so it should make sense that the side opposite \( 30^{ \circ } \) is half of this). We now consider one of these smaller right triangles (see the figure below).

    1.2 30-60-90 newa.png

    The missing side length, which we will call \( x \) for now, can be found using the Pythagorean Theorem.\[\begin{array}{rrcl}
    & x^2 + a^2 & = & (2a)^2 \\
    \implies & x^2 + a^2 & = & 4a^2 \\
    \implies & x^2 & = & 3a^2 \\
    \implies & x & = & a \sqrt{3} \\
    \end{array} \nonumber \]

    The \( 45^{ \circ } \)-\( 45^{ \circ } \)-\( 90^{ \circ } \) Triangle

    Definition: Isosceles Right Triangle

    An isosceles triangle in which the vertex angle is \( 90^{ \circ } \) is called an isosceles right triangle.

    Definition: \( 45^{ \circ } \)-\( 45^{ \circ } \)-\( 90^{ \circ } \) Triangle

    Since an isosceles right triangle has two angles that are \( 45^{ \circ } \), it is commonly called a \( 45^{ \circ } \)-\( 45^{ \circ } \)-\( 90^{ \circ } \) triangle.

    Theorem: Side Relationship for a \( 45^{ \circ } \)-\( 45^{ \circ } \)-\( 90^{ \circ } \) Triangle

    In any right triangle in which the two acute angles are \( 45^{ \circ } \), the hypotenuse is always \( \sqrt{2} \) times the side length.

    1.2 45-45-90a.png
    Proof

    The sides opposite the \( 45^{ \circ } \) angles in a \( 45^{ \circ } \)-\( 45^{ \circ } \)-\( 90^{ \circ } \) triangle must have the same length. Let \( a \) be the lengths of these sides and \( x \) be the length of the hypotenuse, as shown in the figure below.

    1.2 45-45-90b.png

    Since this is a right triangle, we can use the Pythagorean Theorem to find the length of the hypotenuse in terms of \( a \).\[\begin{array}{rrcl}
    & a^2 + a^2 & = & x^2 \\
    \implies & 2 a^2 & = & x^2 \\
    \implies & a \sqrt{2} & = & x \\
    \end{array} \nonumber \]

    Area of a Triangle

    Theorem: Area of a Triangle

    Let \( b \) be the length of one side of a triangle and \( h \) be the altitude height from that side to its opposite vertex. Then the area of the triangle is given by\[ A = \dfrac{1}{2} bh. \nonumber \]

    Proof
    To be done in homework.
